Dreamcast con salida HDMI

This is a purely digital connection to the video bus (using an FPGA and proper HDMI Transmitter chip), and not just a simple "RGB to HDMI" adapter crammed into the DC case.

It will eventually also be used for many other retro machines, like the GameCube and N64 (see my other vids), Atari Jaguar, 3DO, NeoGeo (MVS/AES/CD), Amiga, and many more.

It could also be used with handhelds, like the Game Gear and Atari Lynx, and with other things like video processors / scalers.

There are still some things to be fixed, so you might notice some slightly strange colours in the video, and some colour banding here and there, but you can see the quality is already very good.

Along with the benefits of the best possible picture, it will be more convenient to connect to modern TVs, as many of them are now doing away with "legacy" analog inputs altogether.

(If you like the "scanline look", that will be added to the firmware as an option. I have now tested this, and it works fine, but getting perfect scanlines will depend on the monitor / TV used etc.)

The HDMI board has the digital audio from the Dreamcast hooked up to it too, so that will be passed directly to any modern TV with HDMI input.

The Dreamcast outputs a resolution of 640x480 for 99% of it's games.

Depending on the TV or monitor, this board may require some games to be patched for 60Hz "VGA mode", but almost all games should work.
