He was trying to redirect connections to the inner part of the EXT USB and using it with a USB non-powered Hub then to use just a male-male USB A to the EXT USB, mostly as Pandoras do.
And how do you get a stable connection. Both Ben and he, got the same results following your post in Reddit. What were they doing wrong?
pen_mouth:
Or what did they miss?
I have ordered my female USB to solder when they arrive and test too.
darkdev1hoy a las 17:29
I didn't connected the shield of the USB cable to the ground : I didn't solder a USB femalle connector (only the 4 wires)
Pararegistroshoy a las 17:29
Umm...
for both players or just you?
darkdev1hoy a las 17:30
and the red led stays OFF when I plug the USB cable on my PC
Pararegistroshoy a las 17:30
Ok. It's just the opposite the PCB BT does. It keeps it always on and you don't need to press power button.
darkdev1hoy a las 17:32
I can't press the power button on the CHA, my PC doesn't power the CHA via the USB cable. It works as a generic USB controller, nothing more
Pararegistroshoy a las 17:33
So you simply stripped an USB wire soldered without shielding ground and it worked... Both players or simply P1?
darkdev1hoy a las 17:32
I can't press the power button on the CHA, my PC doesn't power the CHA via the USB cable. It works as a generic USB controller, nothing more
Pararegistroshoy a las 17:33
So you simply stripped an USB wire soldered without shielding ground and it worked... Both players or simply P1?
darkdev1hoy a las 17:34
P1
Pararegistroshoy a las 17:35
Ok. Maybe that's the problem. 5v may not suffice for both players and CHA PCB, but many gamepads just run with 200 mah or a bit more; they should work simultaneously.
darkdev1
ha fijado un mensaje en este canal.
Ver todos los mensajes fijados.
hoy a las 17:36
Pararegistroshoy a las 17:38
The blueprint you put in Reddit. So, just the wiring. No female USB Sockets. That might be the problem and the insistence of using it for two players.
